5-230kWh Rack Mounted Battery ( 51.2V 100/200/314Ah Module WIFI Bluetooth IP54)
- A Grade Lithium-Ion Cells
- Max 11000 Cycles Life
- WiFi & Bluetooth
- 3.5 in. Color Touch Screen
- 2-15 Units Parallel
- 10 Years Warranty
- ODM / OEM
Why Choose Our Products
1. The product provides a 10-year warranty, because we are absolutelyconfident in the product!
2. Using A new A grade lithium iron phosphate cell, max 11000 Cycles @0.5C 80%D0D, you can scan the QR code official website to verify thetrue or false, trace the source!
3.Using advanced technology such as laser welding and PCB process,simple, beautiful and durable.
4. Equipped with intelligent BMS, real-time monitoring voltage, current,temperature, protect voltage, current stability, prevent short circuit.overcharge and overdischarge.
5. Touch screen design to achieve better protection and longer servicelife.
6. Rack-type design, simple installation, space saving.
7. Compatible with 95% of brand inverters.
8. Support 15 devices in parallel with a maximum total capacity of215.04kWh.
9. Support OEM/ODM.
|
Model
|
51.2V100Ah
|
51.2V200Ah
|
51.2V314Ah
|
|
Battery Type
|
A Grade LiFePO4 Battery Cells | ||
|
Nominal Capacity
|
100Ah
|
200Ah | 314Ah |
|
Nominal Voltage
|
51.2V
|
||
|
Nominal Energy
|
51.2kWh
|
10.24kWh | 16.08kWh |
|
Suggested SOC
|
20~100%（customized）
|
||
|
Operating Voltage
|
46.4~57.6V
|
||
|
Suggest Charge/Discharge Current
|
50A
|
80A | 140A |
|
Max Charge Current
|
80A
|
120A | 200A |
|
Max Discharge Current
|
80A
|
120A | 200A |
|
Scalability
|
Max 15 Pcs Park in Parallel
|
||
|
Cycle Life (@25℃, 80%DOD)
|
6000
|
11000 | |
|
Humidity
|
5%-85%
|
||
|
Operating Temperature
|
Charge: 0~50℃, Discharge: -20~60℃
|
||
|
Weight
|
39.5kg
|
78kg
|
118kg
|
|
Dimensions
|
567*355*150mm
|
600*381*240mm
|
745*381*240mm
|
|
Installation Method
|
Rack Mounted
|
||
|
IP Grade
|
IP21
|
||
|
Communication
|
RS485, RS232,CAN
|
||
|
Warranty
|
10 Years
|
||
